battery parameter table
13000mAh
33.6V
3 Kg
384.8Wh
5-40 °C
3-Hr
Capacity
Nominal Voltage
Battery Weight
Energy
Charge ambient Temperature
standard Charging Duration
Charger Parameters
Input Voltage
Input Frequency
Input Current
Output Voltage
Output Current
110 - 240 V AC
50/60 HZ
4.0 A Max
33.6 V
6 A
Battery storage & care
The power system battery must be removed and places separately when the equipment is not in use.
The battery should be stored in a cool and ventilated place.
do not place the battery in direct sunlight or high temperature when placing or charging.
overheating of the battery may cause fire or explosion.
do not drop, crush or puncture the battey. Do not disassemble or modify the battery.
keep batteries out of the reach of children
do not charge the battery below 0°C.
when using the battery below o°C, the battery power will plummer, causing a dramatic reduction in operating time.
for safety reasons, the battery or control handle shall be kept low during transportation. before transportation, please discharge the battery and leave it at about 30% of its capacity.
do not use damaged batteries.
if the battery is stored for a long time, please check the battery power at least once every 3 months and charge the battery to 60%.
